DAIHATSU PS-26D CYLINDER LINER

Get a Price/Quote

MOQ : 10 Units

DAIHATSU PS-26D CYLINDER LINER Specification

Capacity
Standard size / Customizable

Application Areas
Marine, Industrial

Product Type
Cylinder Liner

Type
Others

Material
Alloy Cast Iron

Automatic Grade
Manual

Drive Type
Engine Driven

Dimension (L*W*H)
Customized as per engine specification

Surface Finishing
Honed, Smooth

OEM Standards
Meets/exceeds OEM specifications

Machining Tolerance
0.03 mm

Ovality
0.01 mm

Corrosion Resistance
Yes

Packaging Type
Export standard, protective packing

Cylindricity
0.01 mm

DAIHATSU PS-26D CYLINDER LINER Trade Information

Minimum Order Quantity
10 Units

Supply Ability
100 Units Per Month

Delivery Time
1 Week

About DAIHATSU PS-26D CYLINDER LINER

Technical Specification

Usage/Application	Marine
Type	Marine
Material	Chromium,Sulphur & Molybdenum
Dimension	220 to 280 BHN
Features	High Quality
Size	620mm

DAIHATSU PS-26D CYLINDER LINER

SPARES FOR DAIHATSU PSHTC 26 D
PART NAME	*PART NO.*
EXHAUST VALVE	C102530010Z
EXHAUST VALVE (STL)	C102530020Z
SEAT EXHAUST VALVE	C102540010Z
BUSH VALVE CAGE	C102510030Z
VALVE COTTER	C102440010Z
RETAINER VALVE SPRING
SEAT VALVE SPRING	C102440030Z
VALVE SPRING (INNER)	C102479816Z
VALVE SPRING (OUTER)	C102479815Z
INTAKE VALVE	C102430010Z
GUIDE INTAKE VALVE	C102210030Z
SEAT INTAKE VALVE	C102210040Z
ROCKER ARM INTAKE	C103230010A
ROCKER ARM EXHAUST	C103230020A
ROCKER ARM SHAFT	C103240010Z
ROCKER ARM BUSH C. I.	C103270030Z
PUSH ROD	C103170030Z
PISTON - PST	C101910010B
CYLINDER LINER	C101810010A
CAP PISTON PIN	C101920010Z
PISTON PIN	C101930010Z
CRANK PIN BRG SHELL (1+1)	C101930030A
BOLT CONNECTING ROD	C101930041A
GASKET EXHAUST MANIFOLD	C104070130Z
GASKET INLET MANIFOLD	C104270010Z
GASKET	Z56010700Z
GASKET DELIVERY VALVE	C103600300Z
GASKET F. LOCK BOLT	C103600500Z
GASKET F. PUMP	C103600480Z
GASKET FOR BENJO	C103600470Z
GASKET	Z565001902Z
GASKET FUEL VALVE	Y307730328Z
GASKET	Z565001300Z
O' RING G 105X3.1	Z560210531Z
O' RING 25X6.5	Z230002565Z
O' RING 20X5.5	Z560002055Z
O' RING 32.5X3.0	Z560003330Z
SPRING DELIVERY VALVE	C103600420Z
PISTON PIN BUSH	C101930020Z
BOLT CONNECTING ROD	C101930042A
COMP RING	C101970010Z
COMP RING	C101970020Z
OIL RING	C101970030Z
DELIVERY VALVE ASSEMBLY	C103600040Z
PLUNGER ASSEMBLY 16mm	C103600200Z
PLUNGER ASSEMBLY 17mm	C103600210Z
NOZZLE	Y601130328Z
NOZZLE	Y606130328Z
GASKET CYLINDER LINER	C101870010Z
MAIN BEARING SHELL (REAR) (1+1)	C101730010
MAIN BEARING SHELL (1+1)	C101730020
O' RING	Z560729027Z

Superior Precision and Durability

Designed for optimal performance and longevity, the DAIHATSU PS-26D Cylinder Liner is meticulously machined to achieve exacting tolerances, ensuring reliability even in high-stress environments. Its alloy cast iron construction offers impressive strength and resistance to both wear and corrosion.

Customizable Solutions for Diverse Applications

Available in both standard and customized dimensions, the cylinder liner fits a wide range of engine types. Whether for marine or industrial use, clients may specify requirements to suit specific operational needs, making it suitable for manufacturers, dealers, and suppliers.

Strict Quality Assurance & Protective Packaging

Each cylinder liner surpasses OEM specifications through rigorous quality control. Export-standard, protective packing guarantees safe delivery and preservation during transit, ensuring that it reaches customers in optimal condition wherever they are located.

FAQs of DAIHATSU PS-26D CYLINDER LINER:

Q: How does the DAIHATSU PS-26D Cylinder Liner meet OEM standards?

A: The PS-26D Cylinder Liner is manufactured in compliance with or exceeding OEM specifications, with stringent controls on cylindricity ( 0.01 mm), ovality ( 0.01 mm), and machining tolerances ( 0.03 mm), ensuring consistent quality and fit for engine applications.

Q: What process is used to ensure corrosion resistance and wear protection?

A: This cylinder liner utilizes premium alloy cast iron, which undergoes precise machining and surface honing for smoothness. Specialized treatments further enhance its resistance to corrosion and wear, making it suitable for harsh marine and industrial environments.

Q: When is customization available for dimensions or capacity?

A: Customization is offered upon request for specific engine requirements. Clients can specify the desired dimensions (L*W*H) and capacity, aligning with their unique applications in marine or industrial sectors. Standard sizes are also readily available for immediate needs.

Q: Where can the DAIHATSU PS-26D Cylinder Liner be used?

A: This product is ideal for marine and industrial applications where precision, robustness, and reliability are crucial. Its versatility makes it valuable for dealers, distributors, manufacturers, and engine fabricators across India and overseas.

Q: What benefits does the honed surface finishing provide?

A: A honed, smooth surface ensures optimal piston movement and minimizes friction and wear within the engine, leading to improved efficiency and a longer operational lifespan for both the liner and the engine it supports.

Q: How is the cylinder liner packaged for safe transport and storage?

A: It is packed according to export standards, with protective materials that guard against shock, moisture, and corrosion, ensuring the product maintains its integrity until installation by dealers or end-users.

Q: What advantages do users gain from this high-precision engine cylinder liner?

A: Users benefit from reliable engine performance, reduced maintenance due to exceptional wear and corrosion resistance, and the option for tailor-made sizing, which ensures perfect integration with existing engine systems.
